Nitinol Tube
Nitinol shape memory alloy is composed of nearly equal atomic nickel and titanium (i.e. 50:50 at% nickel and titanium), with excellent superplastic and shape memory properties, as well as excellent characteristics of biocompatibility, wear resistance, corrosion resistance, high damping, etc., thus becoming a key material in the field of vascular, orthopedics, spine, urology and dentistry. Applications range from neurovascular stents and heart valve frames to orthopedic nails and disposable suture threading devices.
Classification:
Nitinol Tube
Product Details
Product Features
- Raw materials comply with standard ASTM F2063&GB 24627
- OD range：0.20-15.0 mm;
- WT range：0.025-3.0 mm;
- Good uniformity and consistency of wall thickness；
- Grain size ≥8；
- Smooth surface: Ra≤ 0.4μm on the outer surface, Ra≤ 0.6μm on the inner surface;
- High material purity: loose and metal inclusions ≤ 12.0 um; loose and non-metallic inclusions area percentage ≤ 0.5 percent；
- Excellent fatigue resistance, can be used for interventional catheters, valve stents, peripheral stents, neurointerventional stents, etc
Material Properties
- Super elasticity: It can withstand great deformation and restore its original state in the body, which is several times that of other metals.
- Shape memory effect: It can automatically recover from a deformed state to a pre-set shape at a specific temperature.
- Excellent biocompatibility: Good compatibility with human tissues, less likely to cause rejection or allergic reactions.
- Good flexibility: The pipe is soft and easy to pass through tortuous and narrow human blood vessels or cavities.
- Fatigue resistance: able to withstand cyclic loads for a long time without easily breaking, with a long service life.
- Magnetic resonance compatibility: It will not move or generate heat in a magnetic field, and can safely undergo nuclear magnetic resonance examination.
- High corrosion resistance: It can resist the corrosion of human body fluids and maintain long-term stability.
Size Specification
| OD Range (mm) |
OD Tolerance (mm) |
ID Tolerance (mm) |
WT Range (mm) |
WT Tolerance (mm) |
| 0.2≤OD≤0.5 | ±0.002 | ±0.005 | 0.025≤WT≤0.12 | ±0.003 |
| 0.5≤OD≤1.0 | ±0.005 | ±0.008 | 0.025≤WT≤0.30 | ±0.005 |
| 1.0≤OD≤3.0 | ±0.01 | ±0.01 | 0.025≤WT≤0.40 | ±0.008 |
| 3.0≤OD≤6.0 | ±0.01 | ±0.015 | 0.05≤WT≤1.5 | ±0.008 |
| 6.0≤OD≤9.0 | ±0.015 | ±0.02 | 0.07≤WT≤2.0 | ±0.01 |
| 9.0≤OD≤12.0 | ±0.02 | ±0.02 | 0.1≤WT≤2.0 | ±0.01 |
| 12≤OD≤15.0 | ±0.02 | ±0.03 | 0.1≤WT≤3.0 | ±0.01 |
Inner surface：cleaned, Oxide.
External surface：matted, Oxide and ground.。
Mechanical Property
|
Tensile Strength（MPA) |
Elongation（%） |
4% Upper Platform Stress（MPA） | Permanent set after 6% strain（%） |
AF (℃) |
| ≥1000 | ≥10 | ≥380 | ≤0.3 | ≤0.3 |
*All mechanical testing according to ASTM F2516-18 at 20~24°C.
